Product Overview & Matching Application Range
The automatic bottle cartoner machine shown in the picture is the terminal packaging station of our integrated pharmaceutical filling line system, specially developed for finished liquid pharmaceutical containers after filling, capping and Labelling.
It perfectly matches all 11 categories of liquid medicine production lines we supply, including:
Eye drops, nasal sprays, oral solutions, pharmaceutical cartridges, sterile vials, pre-filled syringes, medical oil bottles, inhalation anaesthetic containers, glycerine enema tubes, topical liquid bottles and diagnostic reagent vials.
This cartoner realizes fully unmanned continuous cartoning workflow, replacing manual bottle boxing to eliminate secondary pollution and improve packaging consistency, fully complying with strict cleanroom and GMP pharmaceutical production requirements.
Core Structural Design & Automatic Working Flow
The equipment adopts 304 sanitary stainless steel frame with modular adjustable conveying structure, the internal multi-station layout corresponds to four core automatic procedures:
- Automatic Carton Unfolding & Forming Station Carton blanks are fed automatically, sucked and opened by vacuum cups, positioned and locked on the conveyor track to avoid carton deformation or misalignment.
- Instruction Leaflet Insertion Module Equipped with independent leaflet feeding mechanism, it automatically extracts and inserts drug instructions into empty cartons synchronously with carton conveying, supporting multi-page folded brochures.
- Stable Bottle Loading & Positioning Conveyor (as shown in the image) The green segmented positioning conveyor belt precisely limits single pharmaceutical bottles, pushes finished containers into pre-formed cartons through adjustable push blocks; quick size switching adapts bottles of different heights and diameters without complicated mould replacement.
- Automatic Carton Folding & Sealing Station Front and rear carton flaps are folded in sequence, with hot melt glue or lock-in mechanical sealing optional, to finish tight, neat packaging for finished pharmaceutical products.
All drive and transmission parts adopt food-grade corrosion-resistant materials, easy to disassemble and wipe for daily sanitization in clean workshop environments.
Key Industry Advantages for Pharmaceutical Manufacturers
- Full closed cleanroom structure, no dust accumulation dead corners, compatible with Class D pharmaceutical packaging clean areas, avoiding cross-contamination of finished medicines.
- Wide adaptability for multi-spec packaging: supports small 1ml vials to large oral liquid bottles, flexible adjustment of carton size and conveying speed within 10 minutes.
- Intelligent PLC touch screen control system: real-time monitoring of carton shortage, bottle missing, leaflet blockage and sealing failure, with automatic stop and alarm function to reduce waste of carton materials.
- Stable high-speed continuous operation, seamless online connection with upstream Labelling machines and downstream case packing machines to form a complete turnkey packaging line.
- Compact floor layout design, saves cleanroom workshop space, lower noise and energy consumption compared with traditional large cartoning equipment.
- Humanized quick-release structure for all contact components, no tools required for disassembly, greatly shortening equipment cleaning and model changeover time.
Supporting Integrated Turnkey Filling & Packaging Line Solutions
As a professional pharmaceutical machinery manufacturer with 18 years of R&D experience, we do not supply standalone cartoner machines only. We design complete end-to-end production lines combining bottle washing, depyrogenation sterilization, filling, stoppering, capping, Labelling and final cartoning.
Our technical team customizes cartoning speed, station layout and matching conveying height of the bottle cartoner according to customers’ daily production output, container specifications and cleanroom workshop layout, realizing fully automatic unmanned production from empty bottle feeding to finished carton output.
Complete Full-Lifecycle Technical Support
- Pre-sales service: Free workshop layout drawing, equipment parameter matching and GMP compliance packaging scheme consultation
- Pre-delivery inspection: Complete factory acceptance test (FAT) with real video monitoring before shipment
- On-site commissioning: Overseas professional engineers for machine installation, debugging and operator operation training
- Long-term after-sales: Global supply of original spare parts, 24-hour online technical troubleshooting and regular equipment maintenance guidance
Our automatic bottle cartoner machine acts as the essential terminal packaging equipment for all liquid pharmaceutical filling lines. Its stable automatic operation, sanitary stainless steel construction and wide product adaptability help global pharmaceutical factories simplify packaging workflows, pass GMP factory audits and upgrade finished product packaging quality. If you need a matched cartoning machine for your liquid medicine filling line, contact us to get your customized packaging solution.
